Replacing the Serpentine Belt on a 2008 Acura MDX
The 2008 Acura MDX uses a single serpentine belt to drive the accessory components on the front of the 3.7L V6 engine. It's not complicated in theory, but the routing can be confusing if you've never looked at it before, and the tensioner setup will fight you if you're not prepared. Starting from the crankshaft pulley at the bottom, the belt runs up the right side to the power steering pump, then across to the alternator on the left side, down to the A/C compressor, back up to the idler pulley, and finally loops over the water pump before returning to the crank. The tensioner sits on the left side near the alternator and applies pressure to keep everything tight. If you trace it wrong, the belt will either jump off immediately or you'll have it tangled around two pulleys and nowhere else. I keep a photo on my phone of the actual routing because even after doing this several times, I still catch myself second-guessing the A/C compressor path. The belt has a ribbed side that faces inward toward the engine block, and getting that orientation wrong is the most common mistake I see people make when they're working alone for the first time.
The tensioner is a hydraulic spring-type unit, not the manual bolt-down style you find on older cars. You need a 14mm socket on a ratchet with a fairly long extension to reach the tensioner pulley bolt. A short wrench works but gives you less leverage. I use a half-inch ratchet with a 14mm socket and a 6-inch extension, sometimes with a swivel joint on the end if the angle from underneath the vehicle isn't cooperating. Here's something people miss: the belt routing diagram is actually printed on a sticker under the hood, near the radiator support on the passenger side. It's faded on most 2008 models because Honda/Acura didn't use UV-resistant ink on those stickers. I learned this the hard way when I was on a job a few years back and spent twenty minutes trying to remember the path before I noticed the sticker sitting right there. Peel it carefully with a plastic trim tool and you can usually still read it. When you're releasing the tensioner to remove the old belt, push the tensioner clockwise. It will move toward the engine block, which loosens the belt. Don't force it past the point where the tensioner arm contacts its stop. I once over-rotated the tensioner on a different Acura and cracked the pulley housing. The repair ran about four hundred dollars for the tensioner assembly alone.
Installation goes in reverse order, but here's the practical part: thread the belt onto all the pulleys first except for the last segment, then use the ratchet to compress the tensioner and slip the belt over the final pulley. The trick is keeping the belt from falling off the alternator or idler pulley while you're applying tension. I usually have a second person hold the belt in place, but if you're working alone, a bungee cord looped around the tensioner arm can hold it in the compressed position while you slide the belt on. Takes about thirty seconds to set up and saves you from wrestling with it for ten minutes. One thing worth noting about this engine is the water pump bearing. On the 3.7L V6, the water pump is driven by the same serpentine belt, and if the bearing is starting to fail, you'll notice a high-pitched whining that changes with engine RPM. This often gets mistaken for a belt squeal. The real belt noise from a worn serpentine belt is more of a chirp or squeak that happens on cold starts and goes away after a minute. Water pump bearing noise doesn't go away. If you're already replacing the belt, it's worth spinning each pulley by hand with the belt off and listening for roughness or noise from the water pump and idler pulleys. The correct belt part number for the 2008 MDX is 31110-PLC-A01. Aftermarket equivalents exist from Gates, Continental, and Bando, and they work fine if you don't mind spending less. OEM belts tend to last longer, but I've had Gates belts run sixty thousand miles without issue on a customer's vehicle. The tensioner itself is another story — I wouldn't skip replacing it if the original is showing any play in the bearing. The tensioner on these engines typically lasts between seventy and ninety thousand miles, and if it fails while the belt is still good, you're looking at a tow truck call anyway.
Get the Full Details
Total time for a replacement when you know what you're doing is about twenty to thirty minutes. First time, budget an hour or more. The hardest part isn't the mechanical work; it's figuring out the routing quickly enough before the tensioner retracts on its own and you have to start over. If you want a reference image, the official wiring and routing diagrams are available through Honda's service information portal, which requires a subscription. For free options, a YouTube video showing the actual belt path is worth watching once before you start, and taking a photo of your own vehicle's engine bay with the old belt still on it will save you if something goes wrong during installation. I always take that photo before removing anything. It's a five-second habit that has saved me more than once when I got distracted by a stuck bolt and forgot which way the belt was supposed to go.
