Working with Predock's Earth-Supported Forms
You want to build something in the mode of those spiral rammed-earth houses he's famous for. I've poured enough adobe in the desert to know where things go wrong before they go wrong. The fundamental approach isn't complicated, but getting the structural integrity right without modern rebar reinforcement takes actual planning. Start with a floor plan that follows the curvature of the land rather than fighting it. His Houses work because they use the earth itself as a thermal and structural mass. The walls are typically 18 to 24 inches thick, sometimes more, and they're laid in continuous lifts of compacted earth.
Antoine Predock Houses construction details
When you're pouring these walls yourself, the soil mix matters more than anything. Get the clay content right and you're golden. Too much sand and it cracks. Too much clay and it warps as it dries. I learned this the hard way on a project outside Santa Fe where I used local soil without testing. The walls bowed six inches over three months of curing. Took me two weeks of shoring and re-forming to fix it. The workaround I use now is a simple jar test before committing any soil. Fill a mason jar three-quarters full with your raw earth, top it off with water, shake it until it's soupy, and let it settle for 24 hours. The layers that form tell you exactly what you're working with. Sandy bottom means too much sand. Slimy clay layer on top means too much clay. The sweet spot is roughly 15 to 20 percent clay by volume. Once I started doing this, my failure rate dropped from about 40 percent to under 10 percent. Formwork is where most people lose patience. Predock's signature curved walls require custom forms, usually built from bent plywood or even flexible metal lath attached to wooden stakes driven into the ground. The curves need to be continuous and smooth. Any kink or angle in the form will show up in the finished wall as a weak point. I've seen builders try to approximate curves with segmented straight forms. It looks acceptable from a distance but creates internal stress points that crack under thermal expansion.
Another thing nobody talks about: the compaction sequence. You don't just dump earth into the form and walk on it. Each lift should be no more than four to six inches loose before compaction, and you compact in overlapping passes until you get a density reading of at least 90 percent of maximum dry density. A simple nodding style compactor rented from an equipment yard does the job. Skipping proper compaction is the number one reason these walls fail within the first year. There's also the roof situation. The flat or low-slope roofs on these houses need significant overhangs and careful waterproofing. The earth walls wick moisture differently than conventional framing, and if water gets behind the roof membrane it sits there. I use a modified bitumen flashing system with a drainage plane, and I always extend the drip edge well beyond the wall face. Standard residential drip edges just don't move enough water away from massive earth walls. The downside is time. A typical Predock-style house of 1,500 square feet takes roughly 8 to 12 weeks of wall construction alone, assuming decent weather and a crew of three to four people. If you need something built faster, this isn't the method. Conventional stick framing with insulation will get you a weather-tight shell in two to three weeks with similar labor costs, though you'll pay more long-term in heating and cooling.
Get the Full Details
Also worth noting: building codes in many counties still treat rammed earth as an alternative method rather than a standard one. Expect plan review to take longer and bring your engineer to the table early if you want smooth approval. I've had projects stalled for six weeks waiting on structural calculations for wall thickness that my gut told me was fine from the start. If you're serious about this, grab a copy of "Rammed Earth: A Comprehensive Guide" by Wayne and Laura Berger. It covers the mix designs and compaction specs better than anything else I've found. The section on seismic reinforcement for earth walls is especially relevant if you're outside the central New Mexico area where Predock's own work sits comfortably on stable bedrock.
