The pGLO Plasmid Transformation Protocol
The standard Ap Biology Transformation Lab involves introducing a plasmid into competent E. coli cells, then selecting for successfully transformed bacteria on ampicillin and arabinose plates. It sounds straightforward on paper, but the margin for error is surprisingly narrow, and most student groups end up with either zero colonies or a lawn of untransformed cells growing everywhere. You start with chemically competent E. coli cells, typically supplied as a frozen suspension. Keep them on ice the entire time outside of the freezer. Warmth activates nuclease degradation and kills the competence. I learned this the hard way when a subunit accidentally left the ice bucket for forty-five seconds during a teaching session. We lost roughly sixty percent of that batch. Not recoverable. Add the pGLO plasmid DNA to the cells. The plasmid carries three key genes: the bla gene for ampicillin resistance, the GFP gene for green fluorescent protein, and the araC regulatory gene that controls GFP expression only in the presence of arabinose. Mix gently by flicking the tube. Do not vortex. Vortexing shears the cell membrane integrity you just spent money maintaining.
Incubate on ice for ten minutes. This allows the DNA to adsorb to the cell surface. Then heat shock at exactly 42 degrees Celsius for forty-five seconds. That specific duration matters more than you might think. I once ran a trial at thirty seconds out of habit, and transformation efficiency dropped by a factor of three. Then immediately return the tubes to ice for another two minutes. The thermal shock creates a temporary gradient that drives the plasmid through the membrane. Add nine hundred microliters of LB broth or SOC medium and incubate at three hundred seventy degrees Celsius for ten to fifteen minutes. This is the recovery phase where the cells express the ampicillin resistance gene before you plate them. Skipping or shortening this step is the single most common reason students get zero growth on their selective plates. The cells are still recovering from the heat shock and simply cannot synthesize the beta-lactamase enzyme fast enough to survive the antibiotic. Centrifuge briefly, resuspend in two hundred microliters, and plate onto your four agar plates: LB only, LB with ampicillin, LB with ampicillin and arabinose, and LB with ampicillin, arabinose, and the plasmid DNA. Spread evenly using a sterile loop or spreader. Incubate upside down at three hundred seventy degrees Celsius for approximately sixteen to twenty-four hours.
Expected results are specific. The LB plate should show a confluent lawn of non-transformed cells growing freely. The LB with ampicillin plate should show zero growth, confirming the antibiotic is active. The plate with both ampicillin and the plasmid should show scattered green colonies after UV light exposure or sometimes visible without it depending on expression level. The LB plus ampicillin plus arabinose plate without plasmid is your negative control and should show nothing.
Get the Full Details
What Actually Goes Wrong
The most frustrating edge case I encountered involved seemingly perfect competent cells and fresh plasmid, yet every single plate showed heavy background growth of non-green colonies on the ampicillin plates. We were transforming with pGLO, so all resistant colonies should have been green under the right conditions. After ruling out ampicillin degradation and checking the plasmid prep by gel electrophoresis, the issue turned out to be endogenous resistance. The E. coli strain we were using, XL1-Blue, occasionally harbors low-level chromosomal ampC beta-lactamase expression at elevated temperatures. Switching to DH5-alpha eliminated the problem entirely. The protocol works, but the strain choice matters more than the manual usually acknowledges. Another common failure mode is plasmid quality. If your prep was done by miniprep rather than buying a certified kit, residual ethanol from the wash step can kill competent cells during the transformation. Even small carryover volumes, anything over five microliters of seventy percent ethanol in the fifty-microliter cell suspension, will tank your efficiency. Always air-dry the ethanol wash step for at least five minutes, and never use a vacuum centrifuge to dry the pellet completely. A visibly dry pellet means you've over-dried and the DNA becomes nearly impossible to resuspend. The arabinose concentration is another variable people gloss over. Too much arabinose can actually repress GFP expression through catabolite repression mechanisms involving CRP-cAMP complexes. The standard protocol calls for zero point two molar arabinose, but I've seen lab manuals suggest anything from zero point zero zero two to zero point two molar. The sweet spot for visible fluorescence without toxicity is around zero point four millimolar, which translates to roughly zero point zeroseven percent w/v in standard LB agar. Deviating from this range gives you colonies that look healthy but glow dimly or not at all under UV.
Quantifying Transformation Efficiency
Your AP exam may ask you to calculate transformation efficiency, which is colonies per microgram of DNA. The formula is straightforward: count the colonies on the LB plus ampicillin plus arabinose plate with plasmid, divide by the mass of plasmid DNA actually spread on that plate. Mass is calculated from the concentration of your plasmid prep in micrograms per microliter multiplied by the volume added, times the fraction of the total cell suspension that you plated. A typical successful transformation yields between one hundred and one thousand colonies per microgram. If you're getting numbers in the tens of thousands, check whether your ampicillin plate is actually selective. If you're getting below ten, your competent cells are likely past their prime or the heat shock timing was off. Transformation efficiency declines sharply after the competent cell thaw-refreeze cycle. Aliquot your competent cells into single-use volumes of fifty microliters immediately upon receipt. Thawing and refreezing any batch reduces efficiency by roughly an order of magnitude. The GFP expression timing is also worth noting. Colonies may appear white initially and only turn green after extended incubation or exposure to UV light. The araC protein needs time to bind the araO2 and araI operator sites and recruit RNA polymerase. Don't discard a plate as a failure after six hours. Check again at twelve and twenty-four. I've had groups write up negative results prematurely because they looked at the plate too early.
