Why I Rebound the Old Testing Handbook Anyway
The industry keeps pushing new digital measurement systems and cloud-based test management, but when I have to actually design a high-voltage test setup from scratch, I still open the second edition of High Voltage Engineering And Testing Second Edition by Hans Müller as my first reference. It reads like a manual written by someone who spent thirty years debugging real equipment instead of writing textbook problems. The coverage of impulse generators, the treatment of measuring circuits, and the sections on insulation coordination still hold up better than most of the papers I see circulated at conferences. Most people dismiss it because the diagrams look dated and the terminology sometimes drifts away from IEC 60060 language. That is a fair complaint, but it does not mean the content is wrong. I spent years trying to get clean switching impulse results on a 500 kV tank and kept chasing ghosts in the measurement chain until I went back and re-read the chapter on attenuator compensation. The problem was never the surge generator. It was the capacitive voltage divider I had chosen based on a datasheet that listed bandwidth but omitted the high-frequency phase angle response. The book calls this out in a way that modern product manuals usually skip entirely.
Getting Started With High Voltage Engineering And Testing Second Edition
Start with Part One, the fundamentals. The early chapters on corona, streamer propagation, and breakdown mechanisms are dense but practical. Do not jump straight into the testing chapters. The theory sections are where the book earns its keep, especially the discussion on statistical versus deterministic breakdown in non-uniform fields. If you are working on gas-insulated switchgear or extruded cable systems, those sections will save you hours of reading peer-reviewed papers that arrive at the same conclusions years later with fancier computer models. After the fundamentals, move into the measurement chapters. The treatment of rod-gap measurements, resonant test circuits, and impulse wave shaping is thorough. The book does not shy away from the messy details like the effect of humidity on sphere gap correction factors or the subtle difference between actual and standard lightning impulse waves. It gives you the correction formulas and the reference tables. You can trust them. I have used the switching impulse correlation data from that edition on projects up to 800 kV and the numbers still matched field results within the expected scatter band.
What the Book Gets Wrong And What It Misses
The biggest gap is the lack of coverage on partial discharge measurement standards as they evolved after the book was published. IEC 60270 has been revised multiple times since this edition came out. The core principles are the same, but the acceptance criteria, calibration procedures, and digital filtering recommendations have changed. If you are designing a test lab to current IEC compliance, you will need to supplement this book with the latest version of IEC 60270 and possibly the CIGRE working group documents on PD signal processing. Another limitation is the treatment of power electronics-based test sources. The book focuses heavily on conventional capacitor discharge circuits and transformer-based AC test sets. Modern labs frequently use voltage source inverters for AC testing and modular pulse power converters for impulse generation. The principles described in the switching and impulse chapters still apply, but the hardware implementations have diverged significantly. I had to figure out the compensation network for a solid-state impulse generator on my own, and the book gave me the theoretical foundation but not the topology-specific guidance I needed. There is also a noticeable blind spot around renewable energy applications. The book was written before wind turbine lightning protection and large-scale solar inverter insulation stress became major engineering concerns. If you are working in those areas, you will find the general impulse testing methodology useful but the application examples irrelevant. The underlying physics has not changed, but the component characteristics and failure modes are different enough that you need supplementary references.
Get the Full Details
A Real Problem I Ran Into And How I Solved It
I was testing a 245 kV GIS assembly with a 1.2/50 microsecond lightning impulse. The front of the wave kept rounding off, and the peak voltage was consistently 8 percent below the calculated value. I replaced capacitors, checked connections, adjusted the gap spacing, and still got the same result. I went back to the section on wave shaping resistance and inductance in the impulse generator chapter. The author mentions that the tail resistor placement can introduce an unintended parallel capacitance path when the resistor is mounted too close to grounded structures. I moved the tail resistor bank farther from the grounding grid, added shielding between the resistor and the ground plane, and the wave shape normalized within two test shots. The book did not give me a step-by-step fix for that exact scenario, but it gave me the principle that made the solution obvious once I saw it. This kind of thing happens all the time in high voltage testing. The instruments tell you something is wrong but not what is wrong. The textbooks from the seventies and eighties often describe the physical layout issues that modern compact equipment designs inadvertently reintroduce. That is why I keep this edition on the shelf alongside the current IEC standards. They complement each other rather than compete.
How to Actually Use This Book in a Modern Lab
Use it as a reference during test planning, not as a procedural manual. When you are sizing a capacitive divider for a 1000 kV DC test, the book walks you through the calculation of division ratio uncertainty across frequency components. That is more useful than any quick-reference card I have seen. When you are specifying an impulse generator for a new test facility, the chapters on spark gap design and waveform tolerance give you the parameters you need to talk to manufacturers with some authority. Most vendor quotations assume the buyer knows less than they do. This book levels that gap. Do not use it as the sole basis for safety procedures. The safety sections are basic and reflect the standards and practices of the era in which the book was written. Modern labs follow IEC 61936 and IEEE standards for substation and laboratory safety. The book will not keep you alive in a high voltage environment. Read it for the technical depth and follow current safety codes for everything else. If you are a student, start with the measurement chapters and work backward into the theory. The applications make the theory easier to absorb. If you are a practicing engineer, bookmark the impulse testing and high voltage measurement sections. Those are the ones you will reach for repeatedly. The rest of the book is solid reference material but less likely to come up in day-to-day work unless you are dealing with insulation coordination for extra-high voltage transmission systems.
The Bottom Line Without a Bottom Line
The second edition of High Voltage Engineering And Testing Second Edition is not a complete replacement for current standards or modern textbooks. It has gaps in partial discharge standardization, power electronics test sources, and renewable energy applications. But for the core disciplines of impulse testing, AC and DC high voltage measurement, and basic insulation coordination, it remains one of the clearest and most practically oriented books available. The writing is straightforward. The derivations are correct. The examples are grounded in actual test experience. I would rather read forty pages from this book than flip through two hundred pages of marketing-heavy technical manuals that promise more than they deliver.
