Working With the NJATC Photovoltaic Systems Workbook

The NJATC photovoltaic systems workbook is used in the electrical apprenticeship program. It covers solar installation, code compliance, system design, and safety. The answer key helps you check your work after completing the assignments. It is not a shortcut to pass exams. It is a verification tool. I have seen apprentices treat the answer key like a crutch. They fill in blanks without doing the math. Then they get on a job site and cannot size a conduit fill or calculate voltage drop. The workbook problems are grounded in NEC requirements. The answer key reflects those requirements. If you skip the process, you are just memorizing numbers that will not stick under pressure. The workbook covers DC and AC side calculations. It asks you to determine array voltage, current, wire sizing, overcurrent protection, grounding conductor size, and disconnect requirements. It also has questions on parallel and series string configuration. The answer key gives you the final values. That is it. The value is in comparing your steps to the key and finding where you went wrong.

Here is how I use it. I complete a problem. I write out every step on a scratch pad. I check my final answer against the key. If it matches, I move on. If it does not, I trace back to the first mismatched number. Usually I miss a temperature correction factor or round a wire size up to the next standard option. The key catches that. It forces me to see the error instead of assuming I was correct. One specific issue I ran into was with the answer key for a problem involving module open-circuit voltage at low temperature. The workbook gave a specific winter temperature for the location. I used the standard -4 degrees F assumption from the NEC table. The answer key used a different value because the problem statement specified a local minimum of -10 degrees F. I kept getting the wrong answer until I re-read the problem carefully. The key assumes you follow the problem data, not generic defaults. That is a recurring theme in these workbooks. Read the problem statement twice before pulling a table value. The answer key itself is usually distributed by the training center or included in the instructor materials. Some apprentices find posted versions online. I do not recommend relying on unofficial copies. They sometimes have typos or outdated code references. The 2020 NEC edition changed some PV calculations. Make sure your key matches the edition your program is using.

There are limits to what the answer key can do for you. It cannot teach you how to interpret a manufacturer datasheet. It cannot replace hands-on training with actual racking, conduit, and inverters. I had an apprentice who could solve every workbook problem perfectly. He still installed a ground fault protector backward on his first real array because he had never held one. The workbook is theory. The answer key is theory verification. Real competence comes from mixing both. Another thing beginners miss. The answer key often shows rounded values. Your intermediate calculations may look different but still arrive at the same final number. Do not assume you are wrong just because a mid-step value does not match exactly. Track whether rounding happened at each stage. That usually explains the gap. If you are studying for the NJATC PV exam, the workbook is part of the curriculum. Use the answer key honestly. Complete the problems first. Check your work. Note the patterns in your mistakes. Repeat. It takes about an hour per chapter if you do it properly. Rushing through it in thirty minutes by only checking answers is not studying. It is guessing.

The material builds on itself. You need to understand series versus parallel before you touch array sizing. You need conduit fill basics before you attempt conductor placement questions. If you are stuck, go back to the earlier chapters. The answer key will not help you there. Understanding will.
