Working with Schlepper Lifting Mechanism Spare Parts When Granite Components Are Involved
The Hubwerk on a Schlepper floor sweeper is the hydraulic lifting assembly that raises and lowers the sweeping drum or brush carrier. When granite rollers or granite-coated components are part of that assembly, things get more specific and sometimes more frustrating than standard spare parts work. I have replaced enough of these over the years to know where the gotchas hide. Granite is used in certain Schlepper models as a counterweight material or as the surface material for specific drum types. It is dense, dimensionally stable, and resistant to wear, which is why some manufacturers chose it. The problem is that granite components are not generic. They are often custom-molded or custom-cut for a particular machine serial number range, and they come with specific mounting patterns, weight tolerances, and balance requirements. When you are searching for Hubwerk Ersatzteile for a machine that uses granite components, start by identifying the exact model and serial number range. Schlepper produced several sweeper lines over the decades, and the Hubwerk geometry changed between them. A lifting arm from a 1980s model will not bolt onto a 1990s version even if the overall machine looks identical. I learned this the hard way on a Fimaschlepper S 550 where I ordered replacement lift cylinders based on the visible part numbers, only to find the mounting bracket spacing was 4 millimeters off. That 4 millimeter difference meant the cylinder would not align with the lifting eye on the drum carrier. The workaround was to fabricate small adapter sleeves from hardened steel tubing, bored to fit the pin and outer-dialed to take the cylinder mount. It held for years. It is not something I recommend for a new build, but it keeps an old machine running when the exact bracket is no longer manufactured.
Here is the practical sequence I follow when ordering and installing these parts: Step one is documentation before disassembly. Take clear photos of the Hubwerk assembly from multiple angles before you remove anything. Note the part numbers stamped on the lift arms, cylinder mounts, and any granite component brackets. Write down the machine serial number. Take a picture of the serial plate. These details matter more than you might think because Schlepper spare parts catalogs are not always synchronized with production changes, and dealers often cross-reference by serial number rather than model name alone. Step two is identifying which granite component you actually need. Granite parts in the Hubwerk area typically fall into two categories: counterweight blocks that are bolted to the lift arm assembly to balance the drum carrier, and granite-faced roller sections that are part of the sweeping drum itself. These are not interchangeable. A counterweight block serves a completely different function than a drum face, and the mounting hardware, weight tolerance, and balancing requirements are different. If you order the wrong one, you will notice immediately when the machine tilts or the drum hangs at an angle.
Step three is sourcing. Original Schlepper Ersatzteile for older machines can be difficult to find through regular dealership channels. Many of these parts are now only available through specialized industrial spare parts dealers who focus on floor sweeping equipment. Some granite components may need to be fabricated by a stone shop familiar with precision mounting, especially if the original casting is cracked or the mounting holes have elongated. This is one area where the part itself is not expensive, but the total cost including fabrication and balancing can add up quickly. Budget accordingly. Step four is installation and alignment. When you reinstall the Hubwerk with new or replacement parts, check the following before you reconnect the hydraulic lines. The lift arms should move through their full range without binding. The pins and bushings should have the specified clearance, not play to the point of rattling and not seized tight. If you replaced any granite counterweight, verify the machine sits level when the drum is in both the raised and lowered positions. An unbalanced Hubwerk causes premature wear on the cylinder seals and the lift arm pivot points, and it makes the sweeping action inconsistent. There are a few things about these assemblies that are not obvious and that I wish more people understood before they start tearing into one.
Get the Full Details
Granite components are heavy. A granite counterweight block for a Schlepper Hubwerk can weigh between 15 and 40 kilograms depending on the model. This means the lift cylinders, pivot pins, and mounting brackets are sized for that load. If you replace a granite block with a lighter material without adjusting the system, you introduce a balance problem. The drum carrier will tend to droop, and the hydraulic cylinder will cycle differently than designed. Some operators substitute steel or cast iron, but if you do that, you need to match the weight as closely as possible, not just the dimensions. A 10 percent weight difference is enough to cause seal wear within a few months. Another thing that catches people out is the hydraulic circuit design. The Hubwerk on most Schlepper sweepers uses a simple open-center circuit with a priority valve or a mechanical lock to hold the drum in position. When you replace cylinders or hoses, make sure the flow direction is correct. These cylinders are not always symmetrical. Installing one backwards will not destroy anything immediately, but it changes the pressure dynamics and can cause the drum to lower too quickly or not hold position under load. I once spent two hours troubleshooting a slow-lower issue on a Schlepper only to discover the replacement cylinder had been installed with the port orientation reversed. The machine worked, but the damping characteristics were wrong, and the drum would bounce when it hit the floor. If you are dealing with a granite drum face rather than a counterweight, the installation is more involved. The granite section is usually bonded or mechanically fastened to a steel core. When replacing it, you need to check the flatness of the mating surface and the condition of the bonding material. Old polyurethane adhesive breaks down over time, and a granite face that is even slightly loose will vibrate itself free during operation. I recommend using a straightedge and feeler gauge to check for gaps greater than 0.5 millimeters around the granite interface. If you find gaps, the part should be re-bonded or replaced rather than forced back into service.
The main limitation you will run into with Schlepper Ersatzteile Hubwerk Ersatzteile Granit is availability. Schlepper as a brand has gone through ownership changes and production shifts, and many spare parts SKUs have been discontinued. This is especially true for the granite-specific components, which were only used on certain models during certain production periods. If you cannot find an original part, your options are a compatible aftermarket alternative, a fabricator who can reproduce the component, or in some cases, a donor machine from a scrapyard. The scrapyard route is risky but sometimes necessary for obsolete parts. If you go that route, inspect the Hubwerk on the donor carefully before cutting it apart. A used cylinder with worn internals is worse than no cylinder at all because it will fail again within weeks. For the actual replacement parts themselves, the critical dimensions to verify are the pin diameters, the mounting hole patterns, the cylinder rod diameter, and the overall extended and retracted lengths. These should match the originals within 1 millimeter. Anything beyond that and you are looking at modification work that may compromise the structural integrity of the assembly. One final note on maintenance. The Hubwerk pivots and cylinder rods should be lubricated on a regular schedule, and the granite components should be inspected for cracking at least once per season. Granite is durable but not indestructible, and thermal cycling combined with vibration can produce micro-cracks that are not visible during a casual inspection. A hairline crack in a granite counterweight or drum face can propagate until the component fails catastrophically while the machine is running. That is not a theoretical risk. I have seen it happen.
