Setting Up Wireless on the HP LaserJet M1217nfw
The M1217nfw is an older MFP that supports wireless only through WPS or manual WPA2 configuration. It does not support WPA3 and its built-in Wi-Fi module is 802.11b/g only, so it will not connect to a 5GHz network at all. You need to know that going in. The control panel is a small two-line LCD with five buttons. There is no touchscreen, no web interface you can reach before the network is configured, and no NFC tag. That means the entire setup has to be done button-by-button on the device itself or through HP's software on a computer. Getting through it without reading ahead first usually takes longer than it should.
Hp Laserjet M1217nfw Mfp Wireless Setup Manual
I found a copy of the official manual here: HP LaserJet Pro M1217nfw All-in-One series - Wireless Setup Manual. Downloading it saves you from searching through support pages later. The section you care about is Chapter 4, "Setting Up Wireless Network Connections." Method one uses WPS push-button authentication. If your router has a WPS button, press it within two minutes of initiating the wizard on the printer. Here is the sequence: Press the Wireless button on the printer control panel. Use the right arrow to select Settings, then press OK. Scroll to Wireless Setup Wizard and press OK. The printer scans for available networks and displays them. Select your 2.4GHz network and press OK. When prompted, choose WPS and press OK. Press the WPS button on your router. The printer connects, prints a network configuration page, and returns to the idle screen. That is the fastest path if your router supports WPS, which most consumer routers still do, though enterprise gear often disables it by default.
Method two is manual WPA2-PSK entry. This is necessary when WPS is unavailable or disabled. The process is similar but you enter the passphrase directly on the control panel using the arrow keys and OK button. Every character requires scrolling. A 20-character passphrase with mixed case, numbers, and symbols can take three to five minutes to enter. It is doable but tedious. I ran into a specific problem last year that the manual does not warn you about. After a successful WPS connection, the printer would connect initially but then drop off the network every few hours. The router logged it as a DHCP lease expiration with no renewal attempt. The fix was entering a static IP reservation in the router for the printer's MAC address, which is printed on the network configuration page. Without that reservation, the printer sometimes received a different IP after reboot and the scanning and printing jobs would queue up locally and never send. Method three involves the HP Smart application or the full HP software suite. This is the route most people take on Windows. You install the driver package from support.hp.com, run the setup wizard, and the software searches for the printer on the local network. It pushes the Wi-Fi credentials to the device automatically. This method is more reliable for initial setup than the control panel because it bypasses the tedious character entry. The trade-off is that you need a running Windows or macOS machine on the same network to initiate it.
Get the Full Details
A counter-intuitive detail most people miss is that the M1217nfw does not support ad-hoc or peer-to-peer wireless connections. It only works in infrastructure mode with an access point. If you try to connect it directly to a laptop without a router, it will not work. Another thing that trips people up is that the printer's internal print server handles bidirectional communication over the network, but scan-to-network and email scanning require additional configuration on the device's embedded web server, which only becomes accessible after the wireless setup is complete. The firmware on this model is dated. The latest version I checked was from 2019. There is no automatic firmware update feature built into the device, so you have to manually check and download updates from HP's support site when problems like the DHCP issue arise. That is a limitation worth noting upfront. If your router has disabled WPS and you are not comfortable entering a long WPA2 key with arrow keys, the software-based setup method is the practical choice. It avoids the manual entry entirely and configures the wireless settings through a USB connection first, then switches the printer to wireless mode during installation. This usually completes in about ten to fifteen minutes depending on your network environment.
The manual also covers Ethernet fallback, which is worth considering if wireless stability remains a problem. The M1217nfw has a built-in Gigabit Ethernet port, and wired connections eliminate the DHCP lease issues, the 5GHz incompatibility concern, and the intermittent drops that some users report with the 2.4GHz module in congested environments.
